PAGE 9

BIASI B/40

Figure 1:Diagram illustrating the location and function of the front and rear boiler tappings.

Boiler Model Length (L)

B-40/6 34.8”

B-40/7 39.5”

B-40/8 44.5"

B-40/9 49.2"

B-4/10 53.9"

B-4/11 58.8"

B-4/12 63.9"

2.5” MPT Return

2.5” MPT Supply

8” Breech

Control Panel with

operating aquastats
